424
MOQ:
Default
Port:
Hangzhou
Packaging:
Customizable
Lead Time:
Default
Size:
Default Size
Color:
Default Color
| No. | item | Unit | Test Results | Remark |
| 1 | Density | g/cm3 | 0.86 | GB/T22308 |
| 2 | Maximum Service Temperature | ℃ | 260℃ | GB/T22308 |
| 3 | Minimum Service Temperature | ℃ | (-210℃) | GB/T22308 |
| 4 | Maxium Pressure | 1200Psig | 83 barg | GB/T22308 |
| 5 | Compressibility | % | 59.55 | ASTM F36,GB/T20671.2 PRESSURE 35MPA |
| 6 | Resilience Ratio | % | 11.61 | |
| 7 | Creep relaxation rate | % | 68.32 | ASTM F38,GB/T20671.5 100℃*22hr |
| 9 | Compressibility rate | % | 51.26 | JB/T10688 Pressure 17.25Mpa |
| 10 | Resilience Ratio | % | 14.35 | |
| 11 | Nitrogen leakage rate | m1/sec | 0.16 | JB/T10688 Pressure 17.25Mpa Internal Pressure of Medium(N2):4Mpa |
| 12 | Nitrogen leakage rate | m1/sec | 0.0037 | Pressure :35Mpa Internal pressure of Medium(N2):4Mpa |
| remarks:+ and 0 mean depending on situation.- is not. | ||||
